Features
-
airMAX ac Technology – Provides up to 500+ Mbps real TCP/IP throughput with enhanced TDMA protocol
-
airPrism Technology – Isolates signals and rejects adjacent channel interference for improved SNR
-
Rugged Enclosure – Die-cast aluminum housing protects against harsh outdoor environments
-
RF Analytics – Integrated spectrum analyzer and advanced diagnostics with airView
-
GPS Synchronization – Enables co-located radios to operate interference-free
-
Mobile Management – Dedicated management radio with UMobile app support for easy configuration
-
Seamless Integration – Built-in Rocket mount for plug-and-play with airMAX antennas
The Ubiquiti Networks Rocket Prism 5AC Gen 2 (RP-5AC-GEN2) is a powerful 5 GHz airMAX ac radio BaseStation designed to deliver carrier-class wireless performance in challenging RF environments. With advanced airMAX ac technology, a rugged die-cast aluminum enclosure, and patented airPrism technology, it supports up to 500+ Mbps throughput while ensuring superior noise isolation and scalability.
Seamlessly integrating with RocketDish and airMAX ac antennas, this BaseStation provides reliable long-distance PtP and PtMP links with enhanced RF analytics, GPS synchronization, and mobile management via the UMobile app. Ubiquiti RP-5AC-GEN2 Rocket Prism 5AC Gen 2 with airMAX ac, airPrism, 500+ Mbps throughput, GPS sync, and rugged aluminum design for PtP & PtMP wireless networks.
The Ubiquiti Rocket Prism AC Gen2 (RP-5AC-GEN2) delivers high-performance 5 GHz wireless connectivity with up to 500+ Mbps real TCP/IP throughput. Featuring airMAX ac and airPrism technology, it ensures superior noise isolation, scalability, and carrier-class performance in dense RF environments. Built with a rugged die-cast aluminum enclosure, GPS sync, and advanced RF analytics, this radio is ideal for long-distance PtP and PtMP deployments.
Technical Specifications
| Specification | Details |
|---|---|
| Model / Part Number | RP-5AC-GEN2 |
| UPC | 817882020275 |
| Wireless Frequency | 5 GHz |
| Throughput | 500+ Mb/s |
| Processor | Atheros MIPS 74Kc |
| Memory | 128 MB DDR2 SDRAM |
| Networking Interface | 1 x RJ45 Gigabit Ethernet |
| RF Connections | 2 x RP-SMA waterproof connectors |
| Wireless Security | WPA2 |
| Power Consumption | 9.5 W |
| Operating Conditions | -40 to 80°C (-40 to 176°F), 5 to 95% humidity |
| Certifications | CE, FCC, IC |
| Mount Options | Pole mount with integrated Rocket bracket |
| Dimensions | 9.06 x 3.47 x 1.58" (230.12 x 88.14 x 40.13 mm) |
| Weight | 14.1 oz (400 g) |
