Ubiquiti Wave Pro Access Point – 60 GHz PtP/PtMP Bridge, 5.4 Gbps, 15 km Range, Dual 2.5 GbE + 10G SFP+ Ports

Features:

• High-Capacity 60 GHz Radio – Achieves up to 5.4 Gbps total throughput (2.7 Gbps duplex)

• Long-Distance Connectivity – Point-to-Point (PtP) range up to 15 km; Point-to-MultiPoint (PtMP) up to 8 km with Wave AP

• Dual 2.5 GbE + 10G SFP+ Ports – Offers versatile and high-speed connectivity options

• Integrated GPS & Bluetooth – Simplifies deployment and management

• Weather-Resistant Design – IPX6 rated for durability in harsh outdoor conditions

• Ergonomic Transportation Handle – Ensures easy handling during installation

• Precision Alignment Mount – Facilitates accurate and stable positioning

The Ubiquiti Wave Pro Access Point (WAVE-PRO-US) is engineered for high-performance outdoor wireless networking. Operating in the 60 GHz frequency band, it delivers a maximum throughput of 5.4 Gbps (2.7 Gbps duplex), making it ideal for long-distance Point-to-Point (PtP) and Point-to-MultiPoint (PtMP) deployments.

With a PtP range of up to 15 km and PtMP capabilities extending up to 8 km with a Wave AP, the Wave Pro is suitable for connecting remote locations or extending network coverage across large areas. Its dual 2.5 GbE and 10G SFP+ ports provide flexible and high-speed connectivity options to meet diverse networking needs.

Designed for outdoor use, the Wave Pro features an IPX6 weather-resistant enclosure, ensuring reliable performance even in challenging environmental conditions. The integrated GPS and Bluetooth functionalities simplify deployment and network management, while the ergonomic transportation handle and precision alignment mount facilitate easy installation and optimal alignment.

Whether you're building a high-speed wireless backbone or extending network coverage over long distances, the Ubiquiti Wave Pro Access Point offers the performance and reliability required for demanding outdoor networking applications.

Technical Specifications:

• Model: Wave Pro (WAVE-PRO-US)

• UPC: 810080221024

• Weight: Without mount: 2.8 kg (6.2 lb)

• Dimensions: Ø424.4 x 166.2 mm (Ø16.7 x 6.5")

• Enclosure Material: Aluminum alloy, UV-stabilized plastic

• Mount Material: Stainless steel

• Pole Mount Diameter: 25 to 76.2 mm (1 to 3") on pipe outer diameter

• Wind Loading: 369 N at 200 km/h (83 lbf at 125 mph)

• Weatherproofing: IPX6

• Processor: Quad-core ARM® Cortex®-A53 at 1.4 GHz

• Memory: DDR3L 512 MB

• Networking Interfaces: (2) 2.5 GbE RJ45 ports, (1) 10G SFP+ port

• Max. Power Consumption: 26W

• Power Method: Passive PoE 4-pairs (1, 2+; 3, 6-; 4, 5+; 7, 8-), 44–54V DC

• Power Supply: 48V DC, 0.65A, 2.5 GbE PoE adapter (Included)

• Operating Temperature: -40 to 60°C (-40 to 140°F)

• Operating Humidity: 5 to 95% non-condensing

• Certifications: FCC, IC, CE
