Features:
-
PoE-In & PoE-Out Ports – 1× PoE++ input port supplies power, 4× PoE+ output ports deliver up to 25 W each.
-
46 W Total PoE Budget – Generously powers multiple devices on a single switch.
-
10 Gbps Switching Capacity – Supports up to 5 Gbps of non-blocking throughput.
-
Compact & Weather-Resistant – Durable housing with desktop, wall, or pole mounting options.
-
Full Layer 2 Features – VLANs, port isolation, jumbo frames, port mirroring, storm control, and more.
-
Lightweight Design – Weighs just 230 g (~8.1 oz), easy to install anywhere.
-
RoHS & NDAA Compliant – Security-focused for enterprise and government use.
-
Centralized UniFi Management – Fully manageable via UniFi Network Controller.
-
Efficient Power Use – Only ~5 W power draw (excluding PoE), highly energy-efficient.
-
Ideal for Outdoor Ubiquity – Designed for exposed environments, rugged enough for outdoor deployments.
The Ubiquiti USW-FLEX-3 is a versatile and compact 5-port Gigabit PoE switch designed for flexible deployment in both indoor and outdoor environments. This 3-pack solution features a powerful PoE++ uplink and four PoE+ downlinks, delivering up to 46 W to multiple devices while maintaining a lightweight, weather-resistant form factor.
With advanced Layer 2 capabilities—including VLANs, port isolation, jumbo frames, and more—the USW-FLEX-3 offers enterprise-grade network control without taking up space. Easy to manage through the UniFi Network Controller, this switch is ideal for UniFi deployments that demand durability, streamlined power distribution, and high-performance networking. Lightweight and flexible, it’s perfect for extending connectivity in challenging outdoor locations, small venues, or scalable installations.
Optimize your outdoor network with the Ubiquiti UniFi USW-FLEX-3 5-Port Gigabit PoE+ Outdoor Managed Switch (3-Pack). Designed with one PoE++ input and four PoE+ ports, it delivers up to 46W of total power for cameras, access points, and other devices. With weatherproof housing, fanless cooling, and UniFi Controller support, it ensures reliable performance indoors or outdoors.
Technical Specifications
| Feature | Specification |
|---|---|
| Part Number | USW-FLEX-3 |
| UPC | 817882028684 |
| Weight (each unit) | 230 g (8.1 oz) |
| Dimensions | 122.5 × 107.1 × 28 mm (4.8 × 4.2 × 1.1 in) |
| Ports | 1× GbE RJ45 PoE++ input; 4× GbE RJ45 PoE+ outputs |
| Total PoE Budget | 46 W |
| Switching Capacity | 10 Gbps overall; 5 Gbps non-blocking |
| Forwarding Rate | ~7 Mpps |
| L2 Features | VLANs, port isolation, jumbo frames, port mirroring, storm control, rate limiting, etc. |
| Power Consumption | 5 W (excluding PoE output) |
| Mounting Options | Desktop, wall, or pole mount |
| Environmental Ratings | –40°C to 55°C (up to 65°C at lower PoE), 5–95% noncondensing |
| Compliance | CE, FCC, IC, NDAA |
| Management | Via UniFi Network Controller |
