Ubiquiti UniFi USW-LITE-16-...

Features

  • 16 Gigabit Ports – Connects multiple devices with reliable Gigabit performance.

  • PoE+ Support – 8 × 802.3af/at PoE+ ports deliver up to 30W per port, 45W total budget.

  • High Performance – 32 Gbps switching capacity and 16 Gbps non-blocking throughput.

  • Layer 2 Managed Features – VLANs, QoS, ACLs, jumbo frames, IGMP snooping, and more.

  • Silent Operation – Fanless design keeps operation quiet in offices and homes.

  • Centralized Management – Easily configure and monitor via UniFi Network Controller.

  • Compact & Flexible – Desktop or wall-mountable design with included kit.

  • Certified & Secure – NDAA compliant, CE, FCC, IC, and Anatel certified.

The Ubiquiti Networks UniFi Lite 16-Port Gigabit Managed Switch is a cost-effective solution to expand and manage your growing network with ease.

Featuring sixteen Gigabit Ethernet ports, including eight 802.3af/at PoE+ ports, it provides up to 30W per port with a total PoE budget of 45W—perfect for powering security cameras, VoIP phones, UniFi access points, and more. Delivering a 32 Gbps switching capacity with 16 Gbps non-blocking throughput, the UniFi Lite 16 ensures smooth, efficient traffic handling.

Integrated with the UniFi Network Controller, administrators can configure, monitor, and optimize the network centrally. With a fanless design for silent operation and flexible mounting options, this switch is ideal for both small businesses and home offices.

Technical Specifications

Specification Details
Model / Part Number UniFi Lite 16-Port PoE+
UPC 810010071118
Dimensions 192 × 185 × 44 mm (7.6 × 7.3 × 1.7")
Weight 1.2 kg (2.6 lb)
Port Layout 16 × 1G RJ45 (8 PoE+)
PoE Budget 45W total (30W max per PoE+ port)
Switching Capacity 32 Gbps
Non-Blocking Throughput 16 Gbps
Forwarding Rate 24 Mpps
Supported VLANs 1,000
MAC Address Table 8,000
Packet Buffer Size 0.5 MB
Layer 2 Features LACP, STP & RSTP, IGMP Snooping, ACLs, DHCP Snooping, VLAN isolation, jumbo frames, LLDP-MED, Voice VLAN
Max. Power Consumption 15W (excluding PoE) · 60W (including PoE)
Power Method Universal AC input, 100–240V AC, 50/60 Hz
Power Supply AC/DC, internal, 60W
Enclosure Material Polycarbonate
Form Factor Compact desktop, wall mount
Operating Conditions -15 to 40°C (5 to 104°F), 10–90% noncondensing humidity
Certifications CE, FCC, IC, Anatel
NDAA Compliant Yes
