Features:
-
Wi-Fi 7 (802.11be): Future-proof your network with the latest Wi-Fi standard for ultra-fast speeds and enhanced capacity.
-
5 Spatial Streams: 3×3 on 5 GHz and 2×2 on 2.4 GHz for robust multi-device throughput.
-
Dual-Band Operation: Supports both 2.4 GHz and 5 GHz bands for flexible connectivity.
-
High Throughput: Achieve up to 4.3 Gbps on 5 GHz and 688 Mbps on 2.4 GHz.
-
Extended Coverage: Provides coverage up to 1,750 ft² (160 m²) and supports over 300 concurrent clients.
-
2.5GbE PoE+ Uplink: Simplifies installation with power and data over a single cable.
-
Flexible Mounting Options: Suitable for ceiling or wall installations (mounting kit included).
-
Advanced UniFi Features: Includes meshing, band steering, fast roaming, captive portals, RADIUS, PPSK, VLANs, and more.
-
Enterprise-Grade Durability: Operates in temperatures from −30 °C to 50 °C and is NDAA-compliant with CE/FCC/IC certifications.
Elevate your network infrastructure with the Ubiquiti U7-LR Access Point, engineered for high-performance and scalability. Designed for enterprise environments, this Wi-Fi 7 (802.11be) access point delivers exceptional speed and reliability, ensuring seamless connectivity for a large number of devices.
With 5 spatial streams and dual-band support, the U7-LR provides robust throughput and extended coverage, making it ideal for dense environments such as offices, campuses, and retail spaces. The 2.5GbE PoE+ uplink simplifies installation by delivering both power and data over a single cable, reducing cable clutter and installation time.
Managed via the UniFi Network Application, the U7-LR offers advanced features like meshing, band steering, fast roaming, and RADIUS support, allowing for a customizable and secure network experience. Its sleek design and flexible mounting options ensure it integrates seamlessly into any environment.
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | U-POE++ |
| UPC | 810177162032 |
| Weight | 448 g (15.8 oz) |
| Dimensions | Ø175.7 × 43 mm (Ø6.9 × 1.7 in) |
| Wi-Fi Standard | Wi-Fi 7 (802.11be) |
| Spatial Streams | 5 (3×3 on 5 GHz; 2×2 on 2.4 GHz) |
| Max Data Rates | 5 GHz: 4.3 Gbps (BW160); 2.4 GHz: 688 Mbps (BW40) |
| Coverage Area | ~160 m² (1,750 ft²) |
| Client Capacity | 300+ devices |
| Uplink Interface | 1 × 2.5 GbE RJ45 PoE+ port |
| Power | PoE+ (42.5–57 V DC); Max power ~14 W |
| Antenna Gain | 5 GHz: 6 dBi; 2.4 GHz: 4 dBi |
| Max TX Power | 5 GHz: 27 dBm; 2.4 GHz: 26 dBm |
| Mounting | Ceiling/Wall (mount kit included) |
| Materials | Polycarbonate & aluminum (body); polycarbonate & galvanized steel (mount) |
| Environmental | −30 °C to 50 °C; 5–95% non-condensing humidity |
| Certifications | CE, FCC, IC; NDAA compliant |
| Management Requirements | UniFi Network v9.1.120+; iOS v10.20.2+, Android v10.21.7+ |
